4 GB RAM / 64 GB STORAGE / YÜKSEK KAPASİTELİ BATARYA, ANDROID 8
MECHANICAL
Dimensions (L x W x H)
214 mm x 118 mm x 21 mm (8.4 in x 4.6 in x 0.83 in)
Weight
550 g (1.21 lb) with standard battery pack
640 g (1.41 lb) with extended battery pack
ENVIRONMENTAL
Operating Temperature
-10°C to 50°C (14°F to 122°F)
Storage Temperature
-20°C to 70°C (-4°F to 158°F)
Humidity
10% to 90% relative humidity (non-condensing)
Drop
1.2 m (4 ft) to concrete at room temp (10°C to 50°C) per MIL-STD 810G
Tumble
Exceeds 200 times at 0.5 m (1.64 ft) per IEC 60068-2-32 specification
ESD
±12 kV Air and ±8 kV Direct
Environmental Sealing
IP64 (IEC 60529)
SYSTEM ARCHITECTURE
Processor
1.8 GHz Qualcomm® SDM450 8-core
Operating System
Android 8 (Oreo), upgradeable to Android Q
Memory
2/4 GB RAM, 32/64 GB Flash
Display
7-inch high definition (1280 x 720) bright color LCD with backlight, outdoor viewable, optically bonded to touch panel
Touch Panel
Rugged, multi-touch capacitive touch panel, optically bonded for extra durability and better sunlight viewability. Automatic detection and configuration utilizing mutual and self-capacitance modes for water rejection and use
Keypad
On-screen keypad, side scan triggers, volume up/down, power button
Audio
Built-in speaker, Bluetooth wireless headset support
I/O Ports
eHomebase: 3 x USB host, 1 x USB client, Ethernet, spare battery charger
USB Vehicle Dock: 1 x USB host
Camera
13-megapixel color camera with autofocus
Sensors
Ambient light sensor, proximity sensor, accelerometer
Storage Expansion
User-accessible microSD card up to 32 GB SDHC, and up to 128 GB SDXC
Battery
Li-ion, 3.8 V, 4000 mAh and 8850 mAh with integrated battery diagnostics
Hours of Operation
8+ hours
Scanning
1D/2D imager options: N3601 (standard) or N6703 (enhanced)
Application Software
Honeywell power tools and demos, Honeywell SDKs for Android
Warranty
One-year factory warranty
WIRELESS CONNECTIVITY
WLAN
IEEE 802.11 a/b/g/n/ac; Wi-Fi certified
Additional WLAN Features
802.11 d/e/h/i/ k/r/u/w (mc with Android P)
WLAN Security
OPEN, WEP, WPA/WPA2 (personal and enterprise)
Supported EAP
TLS, PEAP, TTLS, PWD, FAST, LEAP
Bluetooth
Class 2 V4.2 Bluetooth
Bluetooth Profiles
HFP, PBAP, A2DP, AVRCP, OPP only
NFC
Integrated Near Field Communication
VoIP
Supported
VPN
IPSec V4/L2TP, PPTP
GPS Supported Protocols
GNSS receiver for BeiDou, GPS and GLONASS
