HPE Networking Instant On Switch 24p Gigabit 2p 10GBT 2p SFP+ 1960
DifferentiatorPorts: 24 x 1 G
Uplink ports: 2 x SFP+ 2 x 10 GBASE-T
Power consumptionMaximum:
100-127V: 60W
200-220V: 80W
Idle:
100-127V: 30W
200-220V: 40W
Input voltage100-127VAC / 200-240VAC
Ports24 RJ-45 autosensing
10/100/1000 BASE-T ports
(IEEE 802.3u Type 100BASE-TX, IEEE
802.3ab Type 1000BASE-T, IEEE 802.an
10GBASE-T);
Duplex: 100 BASE-TX: half or full;
1000 BASE-T: full only
10 GBASE-T: full only
2 SFP+ 10 GbE ports 2 RJ-45
autosensing 100/1000/10 GBASE-T ports
Switching capacity128 Gbps
Stacking capabilities4H height
Throughput95 Mpps
Memory and processorSingle-Core ARM v7 Cortex-A9 @800 MHz; 1 GB DDR3; 512 MB NAND flash; Packet buffer size: 1.5 MB
Operating temperature0-40°C, 0-10,000 ft
Management featuresHPE Networking Instant On Cloud; Web browser; SNMP Manager
WarrantyLimited lifetime warranty with 24X7 phone support for the first 90 days and chat support for the entire warranty duration.
Community support is available for the life of the product.
Detailed product descriptionThe HPE Networking Instant On Switch Series 1960 is a scalable solution for growing businesses with heavy bandwidth requirements and empowers your network to meet your business growing needs. With increased bandwidth, simplified network management, and the ability to handle multiple devices, it provides the ideal solution for your business.
Weight3.9 kg (8.7 lb)
Dimensions35.05 x 44.25 x 4.4 cm (13.80 x 17.42 x 1.73 in)
